The GKTECH slip on spacers allow for adjustment of the fitment of your wheels.
The wheel spacers are hub centric to suit Nissans 66.1mm hub and are manufactured to the highest quality in T6061 Aluminium and then hard anodized to further increase the strength.
Available in 3mm, 5mm, 8mm, 10mm, 15mm or 20mm
NOTE: Sold as a PAIR
NOTE#2: 5mm onwards To suit a 73.00mm wheel bore. Will NOT fit with OEM Nissan wheels.
NOTE#3: Sizes 5mm+ Must be used with extended wheel studs (like the ones we sell here: https://au.gktech.com/20mm-extended-wheel-studs)
|Sizes (width)||PCD||Centre bore||Wheel bore|
|5mm||4/5x114.3||66.1mm||To suit 73mm wheel|
|8mm||4/5x114.3||66.1mm||To suit 73mm wheel|
|10mm||4/5x114.3||66.1mm||To suit 73mm wheel|
|15mm||4/5x114.3||66.1mm||To suit 66.1mm wheel|
|20mm||4/5x114.3||66.1mm||To suit 66.1mm wheel|
FAQsDo I need longer studs to run these wheel spacers?
For 3mm spacers Probably not. This comes down to your wheel choice (they all differ a little in design), the rotor hat thickness (can vary a little between brands), and the wheel nuts you're running. In most cases I'd say it's probably safe at 3mm to not run extended studs but it is situational and we do suggest checking that you do have ample thread when securing your wheel nuts. If you aren't sure, take your car to a professional.
For 5mm/8mm/10mm and 15mm, yes, your standard studs are only 26mm in length so spacing them out an extra 5mm+ without the use of longer wheel studs is probably not possible, and if so would be very dangerous.
Do you sell spacers with other bolt patterns?
No, if it's not listed on our website then we don't sell it. We don't do any custom work. Sorry
What's the difference between these slip on spacers and others available?
These wheel spacers are hub centric which means that they ensure that your wheel sits perfectly central to the hub of your vehicle.
What hub size are these spacers made for?
These spacers are made to suit Nissans which are 66.1mm and as such the spacers have an ID of 66.1mm and an OD of 73.00mm.
NissanR32 SKYLINE GTR
R32 SKYLINE GTS-T
R33 SKYLINE GTR
R33 SKYLINE GTS-T
R34 SKYLINE GT-T
S13 CA18 180SX
S13 CA18 SILVIA
S13 SR20 180SX
S13 SR20 SILVIA
Did exactly what it was meant to do and fit like a glove
It was a perfect fit and good quality as well.
Great quality spacers worked a treat and let me clear my suspension with my new wheels
These spacers were perfect fitment and made my whole install that much cleaner. Great product quality.
Very good and Nice Parts and very fast shiping thanks
